| Type: |
Automatic antenna tuner/antenna system |
| Frequency Range: |
10-80 m |
| Voltage: |
13.8 VDC |
| Current Drain: |
Max 2 A |
| Max feed through RF power: |
120 W |
| Dimensions (W*H*D): |
Control unit: 53*63*205 mm. Tuner: 230*85*380 mm |
| Weight: |
Control unit: 700 gr. Tuner: 2.4 Kg |
| Manufactured: |
1987-19xx |
| Other: |
AH-2b antenna element. 160 m extension option. |
