LDG Electronics Z-11

Type: Automatic Antenna Tuner
Frequency Range: 1.8 - 30.0 MHz
Voltage: 11-20 VDC
Current Drain: 10 to 190 mA, 75 mA average. Zero current draw once tuned!
Max feed through RF power: 60 watts (30 watts continuous)
Dimensions: 5(W) x 1.25(H) x 8.5(D) inches
Weight: 15 oz
Manufactured: USA, 200x-200x
Other: Tunes 6 to 800 ohm Loads, Auto Sleep Mode
Related Documents: Manual (1.13 Mb)
