| Type: |
Power Amplifier |
| Frequency Range: |
144-148 MHz |
| Voltage: |
13.8 VDC |
| Current Drain: |
Max: 25A |
| Drive power: |
1-6 (HT setting)
10-45 W (Mobile setting) |
| Maximum output power: |
80 W (Lo Setting)
160 W (Hi Setting) |
| Dimensions (W*H*D): |
192 x 71 x 250 mm (7.56 x 2.8 x 9.84 inches) |
| Weight: |
2.6 Kg (5.73 lbs) |
| Manufactured: |
Japan: 198x-198x (Discontinued) |
| Other: |
Built-in 15 dB GaAs-FET preamp
|
| Related Documents: |
Manual (535 kb) |
