RM Italy KLV-1000
| Type: |
HF/VHF/UHF Linear Amplifier |
| Frequency Range: |
28-30 MHz |
| Voltage: |
Mains |
| Current Drain: |
? A |
| Drive power: |
AM/FM: 1-10 W
SSB/CW: 2-20 W |
| Maximum Power output: |
AM/FM: 300-700 W
SSB/CW: 600-1400 W |
| Impedance: |
50 ohms, input 2*SO-239, output 4*SO-239 |
| Dimensions (W*H*D): |
? mm |
| Weight: |
? Kg |
| Manufactured: |
Italy, 199x-200x |
| Other: |
5*EL519 |
| Related Documents: |
|
|
