Tono 2M-100W
| Type: |
Power Amplifier |
| Frequency Range: |
144-148 MHz (2m) |
| Voltage: |
13.8 VDC |
| Current Drain: |
Max 11 A |
| Drive power: |
10-15 W |
| Maximum output power: |
90 W |
| Dimensions (W*H*D): |
146 x 58 x 202 mm (5.75 x 2.28 x 7.95 inches) |
| Weight: |
1.6 Kg (3.53 lbs) |
| Manufactured: |
Japan: 198x-198x (Discontinued) |
| Other: |
|
| Related Documents: |
User Manual (332 kb) |
 |
