| Type: |
Amateur VHF transceiver |
| Frequency Range: |
TX: 144-148 MHz
RX: 118-180 MHz |
| Mode: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 50 W
Med: 25 W
Lo: 7 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
11-15.8 VDC |
| Current Drain: |
RX: Max 500 mA
TX: Max 12 A |
| Aerial Input: |
50 ohms |
| Dimensions: |
140(W) x 40(H) x 166(D) mm |
| Weight: |
? gr |
| Manufactured: |
19xx-19xx |
| Other: |
81 Memory Channels
16 - Tone DTMF keypad Microphone |
