Next Handheld Transceiver
Back to Alinco Next Handheld Transceiver |
| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | 144-146 / 430-440 MHz |
| Modes: | FM |
| RF Power output: | Hi: 5/5 W Lo: 0.8/0.8 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 6-16 VDC |
| Current Drain: | RX: 25-100 mA TX: Max 1.5 A |
| Aerial Input: | 50 ohms, BNC |
| Dimensions (W*H*D): | 56*124*37 mm |
| Weight: | 315 gr |
| Manufactured: | 200x-200x |
| Other: | 100 memories, CTCSS & DCS |
| Related Documents: |
