| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | 144-146 / 430-440 MHz Steps: 5/10/12.5/15/20/25/30 KHz |
| Modes: | FM/NFM |
| RF Power output: | Hi: 2.5-5 / 2.5-4.5 W (depending on voltage) Lo: 0.8/0.8 W |
| Sensitivity: | Less than -15 dBu (-12 dB SINAD) |
| Selectivity: | 12 KHz or more (-6 dB), 30 KHz or less (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 6-15 VDC |
| Current Drain: | RX: 75 mA (squelched) TX: Max 1.4 A |
| Aerial Input: | 50 ohms, BNC |
| Dimensions (W*H*D): | 56*124*37 mm |
| Weight: | 310 gr (with battery and antenna) |
| Manufactured: | 2003-200x |
| Other: | 100 memories. CTCSS, DCS, DTMF encode. Experimental mosquito-repel feature. 10F3 digital voice option (EJ-47U) |
