| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | TX: 144-146 /430-440 MHz RX: 0.531-10 / 76.1-90 / 108-170 / 380-470 MHz |
| Modes: | TX: FM RX: AM/FM/WFM |
| RF Power output: | Hi: 300-500 mW (depending on voltage) Lo: ? mW |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | 60 dB |
| Voltage: | 3.7-6 VDC |
| Current Drain: | RX: 19-70 mA TX: Max 250-320 mA |
| Aerial Input: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*96*15 mm |
| Weight: | 102 gr |
| Manufactured: | Japan, 2004-200x |
| Other: | |
| Related Documents: |
