Type: | Amateur UHF Transceiver |
Frequency Range: | TX: 440-450 MHz RX: 430-460 MHz |
Modes: | FM |
RF Power output: | Hi: 2-5 W (depending on voltage) Mid: 1 W Lo: 100 mW |
Sensitivity: | N/A |
Selectivity: | N/A |
Image rejection: | N/A |
Voltage: | ? VDC |
Current Drain: | RX: Max ? mA TX: Max ? mA |
Aerial Input: | 50 ohms, BNC |
Dimensions (W*H*D): | 2.1*4.3*1.5 inches |
Weight: | 13.2 oz (with standard battery) |
Manufactured: | 199x-199x |
Other: | 40 memories. DSQ. CTCSS option |
