Alinco DJ-S42

Type: Amateur UHF Transceiver
Frequency Range: 430-440 MHz (Asia)
Modes: FM
RF Power output: Hi: 1 W
Lo: 0.5 W
Sensitivity: N/A
Selectivity: 12 KHz (-6 dB), 35 KHz (-60 dB)
Image rejection: 60 dB
Voltage: 3.7 VDC (battery pack) or 3-6 VDC external
Current Drain: RX: 14-70 mA
TX: Max 1 A
Aerial Input: 50 ohms, SMA
Dimensions (W*H*D): 57*98*28 mm
Weight: 162 gr (with antenna and EBP-60)
Manufactured: 2006-200x
Other: 100 memories
