| Type: | Amateur VHF Transceiver |
| Frequency Range: | TX: 144-148 MHz (USA) RX: 130-174 MHz (5 / 10 / 12.5 / 15 / 20 / 25 / 30 KHz steps) |
| Modes: | FM |
| RF Power output: | Hi: 5 W (@ 13.8 VDC) Lo: 0.8 W |
| Sensitivity: | 0.2 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB), 26 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 7.2 VDC (EBP-65 Ni-MH pack) or 7-16 VDC external |
| Current Drain: | RX: 25-250 mA TX: Max 1.4 A |
| Impedance: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*110*36 mm |
| Weight: | 280 gr (with antenna and EBP-65) |
| Manufactured: | 2007-200x |
| Other: | 200 memories. CTCSS. Submersible. |
