| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | TX: 144-146 / 430-440 MHz RX: 76-108 / 144-146 / 430-440 MHz |
| Modes: | TX: FM RX: FM/WFM |
| RF Power output: | Hi: 1-5/1-5 W (depending on voltage) Lo: 0.5/0.5 W |
| Sensitivity: | N/A |
| Selectivity: | 6 KHz (-6 dB), 15 KHz (-60 dB) |
| Image rejection: | 60 dB |
| Voltage: | 4-15 VDC |
| Current Drain: | RX: 20-220 mA TX: Max 1.8 A |
| Aerial Input: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*97*40 mm |
| Weight: | 335 gr |
| Manufactured: | 200x-200x |
| Other: | 200 memories |
