Back to Alinco Next Receiver |
| Type: | HF/VHF/UHF Receiver/Scanner |
| Frequency Range: | 0.1-1300 MHz (cellular blocked) |
| Modes: | AM/FM/WFM |
| Memory Channels: | 1000 in 10 banks (expandable) |
| Search Banks: | N/A |
| Priority Channels: | N/A |
| Scan Speed: | N/A |
| Search Speed: | N/A |
| Increment Steps: | N/A |
| Scan Delay: | N/A |
| Voltage: | 2.4-3 VDC (2*R6/AA) or 5.4-6 VDC external |
| Current Drain: | 26-140 mA |
| Impedance: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*99*32 mm |
| Weight: | 220 gr (with EBP57) |
| Manufactured: | 2007-200x |
| Other: | CTCSS. Alpha tags
PC-programmable Selectable keyboard system |
| Related Documents: | User Manual (2.09 Mb)
Brochure (212 Kb) |
