| Type: | Amateur UHF Transceiver |
| Frequency Range: | 430-440 MHz |
| Modes: | FM |
| RF Power output: | Hi: 35 W Mid: 10 W Lo: 5 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | 60 dB |
| Voltage: | 13.8 VDC |
| Current Drain: | RX: 0.6 A TX: Max 10 A |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 140*40*174 mm |
| Weight: | 1 Kg |
| Manufactured: | Japan, 2003-200x |
| Other: | CTCSS/DCS. 10F3 digital voice option (EJ-47U) |
| Related Documents: |
