| Type: |
Amateur VHF/UHF Transceiver |
| Frequency range: |
TX: 144-148 / 430-450 MHz
RX: 87.5-108 / 108-174 / 335-480 MHz |
| Modes: |
TX: FM/NFM
RX: AM/FM/NFM/WFM |
| RF Power output: |
Hi: 50/35 W
Mid: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
Main band: 0.2 uV or better (-12 dB SINAD)
Sub band: 0.25 uV or better (-12 dB SINAD) |
| Selectivity: |
FM, -6 dB: 12 KHz or more, -60 dB: 28 KHz or less
NFM, -6 dB: 6 KHz or more, -60 dB: 14 KHz or less |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC +/- 15% |
| Current Drain: |
RX: 400-600 mA
TX: Max 11 A |
| Aerial input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
140*40*185 mm |
| Weight: |
1 Kg |
| Manufactured: |
2002-200x |
| Other: |
202 memories. Detachable control head. Theft alarm. CTCSS & DCS. Twin RX.
1200/9600 bd packet and GPS option (EJ-50U). 10F3 digital voice board (EJ-47U) option
(requires at least two similarly equipped radios) |
