| Type: |
Amateur VHF/UHF Transceiver |
| Frequency range: |
TX: 144-146 / 430-440 MHz
RX: 87.5-108 / 108-174 / 335-480 MHz |
| Modes: |
TX: FM/NFM
RX: AM/FM/NFM/WFM |
| RF Power output: |
Hi: 50/35 W
Mid: 20/20 W
Lo: 5/5 W |
| Sensitivity: |
Main band: 0.2 uV or better (12 dB SINAD)
Sub band: 0.25 uV or better (12 dB SINAD) |
| Selectivity: |
12 KHz (-6 dB), 28 KHz (-60 dB) |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC +/- 15% |
| Current Drain: |
RX: 500-700 mA
TX: Max 11 A |
| Aerial input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
140*40*185 mm |
| Weight: |
1 Kg |
| Manufactured: |
2005-200x |
| Other: |
202 memories. Detachable control head. Theft alarm. CTCSS & DCS. Twin RX.
1200/9600 bd packet and GPS option (EJ-50U). 10F3 digital voice board (EJ-47U) option
(requires at least two similarly equipped radios). The DTMF mike is optional here
in Europe (does anyone know why by the way?). |
| Related documents: |
Service Manual (2.36 MB) |
