| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
TX: 222-225 MHz
RX: 215-230 MHz |
| Mode: |
TX: FM
RX: AM/FM |
| RF Power Output: |
Hi: 50 W
Lo: 10 W |
| Frequency Steps: |
12.5 / 25 / 37.5 / 50 KHz (Europe)
5 / 10 / 15 / 20 KHz (USA) |
| Memories: |
20 Regular (in 2 Banks)
2 Scan Edge Pairs (Program Scan)
RAM Storage With Lithium Battery Backup
1 Temporary Channel
1 Priority Channel |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 0.6 A
TX: Max 10 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
140 x 50 x 182 mm |
| Weight: |
1.4 Kg (3.09 lbs) |
| Manufactured: |
Japan: 1993-199x (Discontinued) |
| <Other: |
CTCSS/PL Encoder |
| Related Documents: |
User Manual (1.2 MB) |
