| Type:
|
HF/VHF/UHF Receiver/Scanner |
| Frequency Range: |
0.495-2450 MHz (Cellular blocked in the U.S.)
5/6.25/9/10/12.5/15/20/25/30/50/100 KHz steps |
| Modes: |
AM/FM/WFM + AM-TV/FM-TV |
| Sensitivity: |
AM (10 dB S/N)
0.495-5 MHz: 1.4 uV
5-30 MHz: 1 uV
118-136 MHz: 0.79 uV
222-330 MHz: 1 uV
FM (12 dB SINAD)
1.625-5 MHz: 0.32 uV
5-470 MHz: 0.25 uV
470-800 MHz: 0.45 uV
800-2000 MHz: 0.56 uV
2000-2300 MHz: 1 uV
2300-2450 MHz: 1.8 uV
WFM (12 dB SINAD)
76-108 MHz: 1 uV
175-222 MHz: 1 uV
470-770 MHz: 1.8 uV |
| Selectivity: |
AM/FM: 12 KHz (-6 dB), 30 KHz (-50 dB)
WFM: 150 KHz (-6 dB) |
| Image rejection: |
N/A |
| Voltage: |
3.6-6.3 VDC |
| Current Drain: |
53-210 mA (backlight and TFT off)
Max 730 mA (TFT on) |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
61*120*33 mm |
| Weight: |
300 gr |
| Manufactured: |
Japan, 2000-200x |
| Other: |
450 memories. Built-in color TFT screen |
| Related Documents: |
User Manual (1.6 MB)
Service manual (2.6 MB) |
