| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz (Europe)
RX: 118-999 MHz |
| Modes: |
TX: FM/FM-N
RX: AM/FM/FM-N |
| RF Power output: |
Hi: 50/35 W
Mid-Hi: 20/20 W
Mid-Lo: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max ? A
TX: Max 12 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
140*40*146 mm (Box), 140*70*34 (Head) |
| Weight: |
1.15 Kg (Box), 290 gr (Head) |
| Manufactured: |
2000-2002 |
| Other: |
Twin RX. External video input for display on the TFT |
| Related Documents: |
User Manual (970 KB)
Service manual (3.5 Mb) |
