| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
144-146 / 430-440 MHz |
| Modes: |
FM/SSB/CW |
| RF Power output: |
FM/CW: 6-45/6-40 W
SSB: 6-35/6-30 W |
| Memories: |
50 Regular
1 Call
2 Scan Edges (Each Band)
10 Satellite |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 2.5 A
TX: Max 16 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
241 94 x 239 mm (9.5 x 3.7 x 9.4 inches) |
| Weight: |
5 Kg (11 lbs) |
| Manufactured: |
Japan: 199x-19xx |
| Other: |
9K6 packet ready |
