| Type:
|
Amateur HF/VHF/UHF Transceiver |
| Frequency Range: |
10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz (23 cm/10 W option, UX-9100) |
| Modes: |
AM/FM/SSB/CW/RTTY (DV/D-STAR option) |
| RF Power output: |
HF(100W)
50 MHz (100W)
144 and 430/440 MHz (75W)
1.2 GHz with optional UX-9100 module (10W |
| Sensitivity: |
|
| Selectivity: |
|
| Image rejection: |
|
| Voltage: |
13.8V DC |
| Current Drain: |
|
| Aerial Input: |
50 ohms, 3*SO-239 + 2*N-Type |
| Dimensions (W*H*D): |
|
| Weight: |
|
| Manufactured: |
Japan, 2009-20xx |
| Other: |
32 bit IF-DSP. Built-in keyer and HF/50 MHz auto-AT
Twin RX, USB-connector
Optional 6 KHz (FL-430) and 3 KHz (FL-431) roofing filters for HF/6 m |
| Related Documents: |
User Manual(41.0 MB)
Pre-Release Brochure (2.14 MB) |
