Icom IC-910H

Type: Amateur VHF/UHF Transceiver
Frequency Range: 144-146 / 430-440 MHz (Europe)
144-148 / 440-450 MHz (USA)
RF Power output: 5-100 / 5-75 W
Sensitivity: N/A
Selectivity: N/A
Image rejection: N/A
Voltage: 13.8 VDC
Current Drain: RX: Max 2.5 A
TX: Max 23 A
Aerial Input: 50 ohms, SO-239 / N
Dimensions (W*H*D): 241*94*239 mm
Weight: 4.5 Kg (without UX-910)
Manufactured: Japan, 2000-200x
Other: 1260-1300 MHz/10 W (UX-910) and DSP (UT-106) option
Dual 9K6 packet ports and built-in keyer. Twin RX
Related Documents: User Manual (3.5 MB)
Service manual (13 MB)
