| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-148 / 430-440 MHz (USA)
RX: 0.5-999 MHz |
| Modes: |
RX: AM/FM/NFM and DV (GMSK 4.8 kbps voice)
TX: FM/NFM and DV (GMSK 4.8 kbps voice) |
| RF Power output: |
Hi: 5 / 5 W
Mid: ? / ? mW
Lo: ? / ? mW |
| Receiver system: |
? conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
3rd IF: ? KHz |
| Memories: |
1304 |
| Frequency Steps: |
5/6.25/8.33/9/10/12.5/15/20/25/30/50/100/125/200 KHz |
| Scan Rate: |
N/A |
| Voltage: |
7.4 VDC (battery pack)
10-16 VDC (external) |
| Current Drain: |
RX: ? mA
TX: ? A |
| Impedance: |
50 ohms, SMA |
| Dimensions (W*H*D): |
? mm |
| Weight: |
? gr (without batteries and antenna) |
| Manufactured: |
2007-200x |
| Other: |
D-Star concept. Alpha tags. Submersible (1 meter/30 minutes).
CTCSS and DTCS. Twin RX |
| Related Documents: |
User Manual (2.59 MB) |
