| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX/RX: 144-146 / 430-440 MHz
RX: 0.495-999.990 MHz
5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 / 200 KHz steps |
| Modes: |
TX: FM
RX: AM/FM/WFM |
| RF Power output: |
Hi: 1.5 / 1 W
Lo1: 0.1 / 0.1 W |
| Sensitivity: |
AM (10 dB S/N)
0.495-5 MHz: 2.2 uV
5-30 MHz: 1.4 uV
118-137 MHz: 1.4 uV
FM (12 dB SINAD)
30-90 MHz: 0.45 uV
90-144 MHz: 0.2 uV
144-148 MHz: 0.18 uV
148-180 MHz: 0.2 uV
350-470 MHz: 0.18 uV
600-940 MHz: 1.4 uV
940-999.990 MHz: 2.5 uV
WFM (12 dB SINAD)
76-108 MHz: 1.8 uV uV
600-800 MHz: 2.5 uV |
| Selectivity: |
(Ham bands)
AM/FM: 12 KHz (-6 dB), 30 KHz (-60 dB)
WFM: 150 KHz (-10 dB), 700 KHz (-20 dB) |
| Image rejection: |
>40 dB |
| Voltage: |
3.7 VDC (Lithium-Ion battery pack, 1800 mAh) |
| Current Drain: |
RX: 80-150 mA
TX: Max 1.5 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
47*81*28 mm |
| Weight: |
160 gr (with battery and antenna) |
| Manufactured: |
2005-200x |
| Other: |
1250 memories in 18 banks. Alpha tags. CTCSS/DTCS |
| Related Documents: |
User Manual (4.85 MB) |
