| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
TX: 144-148 MHz
RX: 136-174 MHz |
| Modes: |
FM |
| RF Power output: |
Hi: 5 W
Lo: 0.5 W |
| Sensitivity: |
(12 SINAD) Less than 0.16µV (typical) |
| Selectivity: |
More than 15 kHz/-6 dB
Less than 30 kHz/-60 dB |
| Image rejection: |
More Than 60 dB |
| Voltage: |
Internal : 4.8-9.6 VDC
External : 4.5-16.0 VDC |
| Current Drain: |
RX: 150 mA
TX: Max 1.4 A |
| Aerial Input: |
50 ohms |
| Dimensions: |
57(W) x 110(H) x 27(D) mm |
| Weight: |
310 gr |
| Manufactured: |
19xx-19xx |
| Other: |
|
| Related Documents: |
Instruction Manual (9.45 MB) |
