| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
50-52 / 88-108 / 144-146 / 430-440 / 1240-1300 MHz |
| Modes: |
FM(F3E) / WFM(Rx) / AM(Rx) |
| RF Power output: |
2 W
|
| Memories: |
100 |
| Tuning Steps (kHz): |
5/10/12.5/15/20/25/30/50/100 |
| Voltage: |
4.5-16 VDC
or specified Battery Pack/Case |
| Current Drain: |
RX: Max 220 mA
TX: Max 1.4 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
58 x 106 x 28.5 mm |
| Weight: |
280 gr |
| Manufactured: |
1999-2001 |
| Other: |
|
| Related Documents: |
User Manual (1.02 MB) |
