| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
144-148 / 440-450 MHz |
| Modes: |
FM |
| RF Power output: |
Hi: 5/5 W
Mid: 0.5/0.5 W
Lo: 15/15 mW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
4.8-9.6 VDC with battery pack or 4.6-16 VDC external |
| Current Drain: |
RX: 35-? mA
TX: Max ? A |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
57*125*36 mm |
| Weight: |
380 gr (with BP-171) |
| Manufactured: |
1995-199x |
| Other: |
109 memories. Clock. Detachable speaker/mike. Twin RX |
| Related Documents: |
User Manual (4.64 MB)
Service Manual (13.4 MB) |
