Icom ID-880D
| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz
RX: 118-1000 MHz (with some gaps) |
| Modes: |
RX: AM/FM/NFM and DV (GMSK 4.8 kbps voice)
TX: FM/NFM and DV (GMSK 4.8 kbps voice) |
| RF Power output: |
Hi: 50/50 W
MID: ??/?? W
Lo: ?/? W |
| Frequency Steps: |
5, 10, 12.5, 15, 20, 25, 30, 50, 100, 200 KHz |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: ?? A
TX: Max ?? A |
| Aerial Input: |
50 ohms, N |
| Dimensions (W*H*D): |
N/A |
| Weight: |
N/A |
| Manufactured: |
Japan, 2009-20xx |
| Other: |
D-Star concept. GPS connectivity |
