| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-148 / 430-450 MHz
RX: 118-174 / 410-470 MHz |
| Modes: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 50/35 W
Mid: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
<0.16 uV (12 dB SINAD) |
| Selectivity: |
12 KHz (-6 dB), 28 KHz (-60 dB) |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 1 A
TX: Max 11 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
140*40*189 mm |
| Weight: |
1.2 Kg |
| Manufactured: |
199x-xxxx |
| Other: |
9k6 packet ready. 280 memories. Alpha tags. Twin RX |
| Related Documents: |
User Manual (2.35 MB) |
