Lafayette Professional-9
| Type: |
HF Receiver |
| Frequency Range: |
0.55-1.7 / 1.6-4.4 / 4.2-12 / 11-31 MHz |
| Modes: |
AM and CW (with BFO) |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
110VAC Mains |
| Current Drain: |
? |
| Aerial Input: |
? ohms |
| Dimensions: |
23(W) x 13(D) x 10.25(H) inches (including knobs) |
| Weight: |
44 lbs |
| Manufactured: |
1936 |
| Other: |
9 Tube line-up: 80, 42, 6B7, 76, (2) 6C6, (2) 6D6, 41
Original Price: kit form $36.75, Wired unit: $44.25 |
| Related Documents: |
|
 |
