| Type: |
HF receiver |
| Frequency Range: |
0.005-30 MHz (60*500 KHz bands) |
| Mode: |
AM/SSB/CW/FSK |
| Sensitivity: |
0.5-30 MHz:
AM: <2 uV (10 dB S/N)
SSB/CW: <1 uV (10 dB S/N)
0.005-0.5 MHz:
25-200 uV (10 dB S/N) |
| Selectivity: |
N/A |
| Image rejection: |
0.5-30 MHz: 80 dB average, 50 dB minimum |
| Voltage: |
11-16 VDC or Mains 115/230 VAC |
| Current Drain: |
Max 200 mA @ 12 VDC + 590 mA for the pilot lamps |
| Aerial Input: |
50 ohms, SO-239 and Hi-Z |
| Dimensions (W*H*D): |
16.5 x 7.62 x 12.75" |
| Weight: |
32 lbs |
| Manufactured: |
1964-1972 |
| Other: |
National's first solid state receiver
New price 1965 in the US: $1295 (without options) |
| Related Documents: |
User Manual (2.92 MB)
Schematic (355 KB) |
