| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 / 1240-1300 MHz (Europe)
RX: 100-200 / 300-520 / 700-1000 / 1200-1320 MHz |
| Modes: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 1/1/0.28 W
Lo: 300/300/170 mW |
| Sensitivity: |
Less than 0.22 uV (12 dB SINAD) |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
3.3-8.4 VDC (4.5 VDC nominal) |
| Current Drain: |
RX: 11-90 mA
TX: 0.22-1.1 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
58*104*27 mm |
| Weight: |
210 gr (including battery and antenna) |
| Manufactured: |
Japan, 1996-199x |
| Other: |
Optional power booster: CPB-710, 20/20/1 W. |
| Related Documents: |
|
