| Type: |
Private Mobile Radio |
Frequency range
depending on version: |
Band AO: 148-174 MHz
Band AG: 146-172 MHz
Band BO: 132-156 MHz
Band EO: 68-88 MHz
Band M1: 105-108 MHz
Band M2: 138-141 MHz (RX Only)
Band P5: 79-88 MHz (TX Only)
Band P8: 96-106 MHz |
| Mode: |
FM |
| RF Power output: |
1W/6W/6-25 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Channel Spacing: |
Type S: 12.5 khz
Type R: 20 khz
Type V: 25 khz |
| Voltage: |
12 VDC |
| Current Drain: |
RX: ?? mA
TX: ?? W) |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
175 x 52 x 190 mm |
| Weight: |
1.8 Kg |
| Manufactured: |
198x-19xx |
| Other: |
1-6 channels (depending on version). XTAL |
| Related Documents: |
Info Sheet (939 kb)
Service Manual (16.7 MB) |
