Mitsubishi NMT450 FT028

Type: Mobile Phone (Analog)
Frequency range: RX: 463.000-467.500 MHz
TX: 453.000-457.500 MHz
System: Double conversion superheterodyne
1st IF: 21.4 MHz
2nd IF: 455 KHz
Type:
RF power output: 3W / 12W / 50W Switchable
Voltage: Mains: 220 VAC
Current Drain: RX: ? A
TX: ? A
Aerial Input: 50 ohms, N-jack (TX), TNC (RX)
Dimensions (W*H*D): 430 x 88 x 400 mm
Weight: 9.2 Kg
Manufactured: 198x-198x (Discontinued)
Other: Without External System Control, The Unit
Defaults To 463.000 (TX)/453.000 (RX)
Related Documents:
