Type: | HF/VHF/UHF Receiver/Scanner |
Frequency Range: | 0.5-1900 MHz |
Modes: | All-mode |
Memories: | 1000 |
Sensitivity: | N/A |
Selectivity: | N/A |
Image rejection: | N/A |
Voltage: | 4.8-6 VDC internal or 9-16 VDC external |
Current Drain: | 20-160 mA |
Aerial Input: | 50 ohms, BNC |
Dimensions (W*H*D): | 69 x 153 x 40 mm |
Weight: | 350 gr (incl. NiCads) |
Manufactured: | 1994-19xx |
Other: | New price 1994 in UK: £479 |
Related Documents: | User Manual (490 KB) Quick Reference (21.4 KB) CU8232 {Optional PC Control Unit} (490 KB) |
