| Type: |
Digital voice and data modem |
| Modulation method: |
OFDM |
| Bandwidth: |
300 Hz - 2500 Hz, 36 carriers |
| Symbol rate: |
20 mS (50 bd) |
| Voltage: |
10-16 VDC (6 VDC possible by jumper setting) |
| Current Drain: |
Max 200 mA |
| Dimensions (W*H*D): |
100*32*158 mm |
| Weight: |
? gr |
| Manufactured: |
200x-200x |
| Other: |
Connects directly to mike and speaker jacks of unmodified transceivers
Capable of video capture and transmission (NTSC standard, PAL after modification)
Uses established G4GUO open protocol |
| Related Documents: |
User Manual (370 KB)
Sales Leaflet (461 KB) |
