Type: |
Digital voice and data modem |
Modulation method: |
OFDM |
Bandwidth: |
300 Hz - 2500 Hz, 36 carriers |
Symbol rate: |
20 mS (50 bd) |
Voltage: |
10-16 VDC (6 VDC possible by jumper setting) |
Current Drain: |
Max 200 mA |
Dimensions (W*H*D): |
100*32*158 mm |
Weight: |
? gr |
Manufactured: |
200x-200x |
Other: |
Connects directly to mike and speaker jacks of unmodified transceivers
Capable of video capture and transmission (NTSC standard, PAL after modification)
Uses established G4GUO open protocol |
Related Documents: |
User Manual (231 KB)
Sales Leaflet (292 KB) |
