Yaesu FL-2100
| Type: |
All-mode HF Linear Amplifier |
| Frequency Range: |
10-80 m |
| Voltage: |
Mains |
| Current Drain: |
? A |
| Drive power: |
30-100 W |
| Maximum Power output: |
SSB: 1.2 KW (PEP input)
CW: 800 W (DC input)
AM: 600 W (DC input) |
| Impedance: |
50-75 ohms, SO-239 |
| Dimensions (W*H*D): |
340*153*285 mm |
| Weight: |
19 Kg |
| Manufactured: |
Japan, 1971-197x |
| Other: |
2 x 572B |
| Related Documents: |
User Manual (2.8 MB) |
 |
