Next Handheld Transceiver
Back to Alinco Next Handheld Transceiver |
| Type: | Amateur VHF Transceiver |
| Frequency Range: | TX: 144-148 MHz RX: 135-174 MHz |
| Modes: | FM |
| RF Power output: | 1.5-5 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 4.8-13.8 VDC |
| Current Drain: | RX: 24 mA squelched TX: Max 1.5 A |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 57*151*27 mm |
| Weight: | 300 gr |
| Manufactured: | 19xx-19xx |
| Other: | 40 memories |
| Related Documents: |
