| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | 144-146 / 430-440 MHz |
| Modes: | FM |
| RF Power output: | Hi: 5/5 W Lo: ?/? mW |
| Sensitivity: | N/A |
| Selectivity: | 6 KHz (-6 dB), 15 KHz (-60 dB) |
| Image rejection: | 60 dB |
| Voltage: | 6-16 VDC |
| Current Drain: | RX: 26-80 mA TX: Max 1.8 A |
| Aerial Input: | 50 ohms, BNC |
| Dimensions (W*H*D): | 56*124*37 mm (with standard battery) |
| Weight: | 280 gr (with standard battery) |
| Manufactured: | Japan, 2004-200x |
| Other: | 10F3 digital voice option (EJ-47U) |
