| Type: | Amateur VHF Transceiver |
| Frequency Range: | 144-148 MHz |
| Modes: | FM |
| RF Power output: | Hi: 350 mW Lo: 50 mW |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 3*LR6 or 3.6-4.5 VDC |
| Current Drain: | RX: 33 mA squelched TX: 260 mA |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 55*102*28 mm |
| Weight: | 185 gr |
| Manufactured: | 19xx-19xx |
| Other: | 20 memories |
