| Type: |
Amateur Transceiver |
| Frequency Range: |
RX: 0.5-30 MHz
TX: 1.8-54 MHz. (Transmit limits vary by country.) |
| Modes: |
All Mode |
| Memories: |
100 general frequency memories with alphanumeric text labeling
plus 4 scratchpad memories per band |
| RF Power output: |
100W or 10W(upgradable) |
| Tuning Steps: |
1/10/20/50 Hz; per-mode
coarse tuning of 1/2.5/5/10 kHz, or user-selected rate. |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: ? mA, TX: Max ? mA |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
Enclosure only: 10.7" x 4.0" x 10.0" (272 x 102 x 254 mm)
with projections: 11.1" x 4.4" x 11.8" (282 x 112 x 300 mm) |
| Weight: |
8.5 lbs. (3.85 kg) max., all options installed |
| Manufactured: |
199x-200x |
| Other: |
|
| Related Documents: |
User Manual (9.31 MB)
Specifications (16.7 Kb) |
