| Type: |
HF/VHF/UHF/SHF receiver/scanner |
| Frequency range: |
0.01-3300 MHz |
| Mode: |
AM/FM/WFM/SSB/CW (Only FM/WFM above 1300 MHz) |
| Receiver system: |
Double conversion superheterodyne (WFM)
1st IF: 266.700 MHz
2nd IF: 10.7 MHz
Triple conversion superheterodyne (All except WFM)
1st IF: 266.700 MHz
2nd IF: 10.7 MHz
3rd IF: 450 KHz |
| Sensitivity: |
AM (10 dB S/N)
0.495-1.8 MHz: 25 uV
1.8-50 MHz: 2.5 uV
50-700 MHz: 2 uV
700-1300 MHz: 2.5 uV
FM (12 dB SINAD)
1.8-50 MHz: 0.63 uV
50-700 MHz: 0.5 uV
700-1300 MHz: 0.63 uV
1300-2300 MHz: 5.6 uV
2300-3000 MHz: 18 uV
WFM (12 dB SINAD)
50-700 MHz: 1.4 uV
700-1300 MHz: 1.8 uV
1300-2300 MHz: 18 uV
2300-3000 MHz: 56 uV
SSB/CW (10 dB S/N)
0.495-1.8 MHz: 5 uV
1.8-50 MHz: 0.5 uV
50-700 MHz: 0.4 uV
700-1300 MHz: 0.5 uV |
| Selectivity: |
AM/FM: 6 KHz (-6 dB), 15 KHz (-60 dB)
WFM: 50 KHz (-6 dB), 230 KHz (-60 dB)
SSB/CW: 2.8 KHz (-6 dB) |
| Image rejection: |
|
| Voltage: |
12 VDC ±15% |
| Current drain: |
Max 1.5 A |
| Impedance: |
50 ohms / 2*BNC |
| Dimensions (W*H*D): |
Box: 146*41*206 mm (5.75*1.61*8.11")
Panel: 140*50*28 mm (5.51*1.97*1.1") |
| Weight: |
Box: 1.35 Kg (2.97 lbs)
Panel: 250 gr (8.82 oz) |
| Manufactured: |
Japan, 2006-20xx (Discontinued) |
| Other: |
CTCSS/DTCS. Dual watch and diversity reception.
Windows software for computer control via USB connector
Also sold without the control panel as IC-PCR2500 for computer control only |
| Related documents: |
User Manual (2.7 MB) |
