| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz (Europe)
RX: 118-174 / 400-479 MHz |
| Modes: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 50/35 W
Mid hi: 20/20 W
Mid lo: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
0.18 uV (12 dB SINAD) |
| Selectivity: |
12 KHz (-6 dB)
30 KHz (-60 dB) |
| Image rejection: |
Better than 60 dB |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: 0.8-1 A
TX: Max 12 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
140*40*185 mm |
| Weight: |
1.17 Kg |
| Manufactured: |
19xx-19xx |
| Other: |
162 memories. CTCSS. 9K6 packet ready. |
| Related Documents: |
User Manual (1.2 MB) |
