| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
EUR: 144-146 / 430-440 MHz
USA: 144-148 / 430-450 MHz
AUS: 144-148 / 430-450 MHz
Sweden: 144-146 / 432-438 MHz |
| Modes: |
FM/SSB/CW |
| RF Power output: |
144 MHz Lo: FM/CW: 6 W / SSB: 6 W
144 MHz Hi: FM/CW: 45 W / SSB: 35 W
430 MHz Lo: FM/CW: 6 W / SSB: 6 W
430 MHz Hi: FM/CW: 40 W / SSB: 30 W |
| Memories: |
50 Regular
1 Call
2 Scan Edges (Each Band)
10 Satellite |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 2.5 A
TX: Max 16 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
241 94 x 239 mm (9.5 x 3.7 x 9.4 inches) |
| Weight: |
5 Kg (11 lbs) |
| Manufactured: |
Japan: 1994-19xx |
| Other: |
9K6 packet ready |
| Related Documents: |
User Manual (5.1 MB) |
