| Type: |
Amateur VHF/UHF transceiver |
| Frequency Range: |
144-148 MHz / 438-450 MHz
(5 KHz steps) |
| Modes: |
FM |
| RF Power output: |
Hi: 2-5/2-5 W (Depending on voltage)
Mid: 2/1.8 W
Lo: 0.35/0.35 W |
| Sensitivity: |
VHF: 0.16 uV (12 dB SINAD)
UHF: 0.18 uV (12 dB SINAD) |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
6-16 VDC |
| Current Drain: |
RX: 20-250 mA
TX: 0.5-1.5 A |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
61*189*43 mm |
| Weight: |
380 gr |
| Manufactured: |
1997-1997 |
| Other: |
CTCSS and DTMF. Twin RX
Removed from the US market only weeks after being
introduced. Appearantly, it was too easy to modify
for illegal use. |
| Related Documents: |
|
