Heathkit

Listed Alphbetically by Model Number

AR Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
AR-1 0.55-20 MHz


Receiver
AR-2 0.535-35 MHz


Receiver
AR-3 0.55-30 MHz


Receiver


AT Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
AT-1 10-80 m


Transmitter


CR Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
CR-1 ?-? MHz AM

Receiver


DF Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
DF-1 0.54-1.6 MHz AM

Receiver
DF-2 0.2-0.4 / 0.54-1.6 MHz AM

Receiver


DX Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
DX-20 10-80 m AM/CW 75 W
Transmitter
DX-35 10-80 m Phone or CW 65 W
Transmitter
DX-40 10-80 m AM/CW 75 W
Transmitter
DX-60 10-80 m AM/CW 50 W
Transmitter
DX-100 10-160 m AM/CW 140 W
Transmitter
DX-100B 10-160 m AM/CW 140 W
Transmitter
DX-100U 10-160 m AM/CW 140 W
Transmitter


EK Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
EK-2A 0.54-1.6 / 3-10 MHz AM/SSB

Receiver
EK-2B 0.54-1.6 / 3-10 MHz AM/SSB

Receiver


GC Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
GC-1 (Mohican) 0.55-30 MHz AM/SSB/CW

Receiver
GC-1A 0.55-30 MHz AM/SSB/CW

Receiver
GC-1U (Mohican) 0.58-30 MHz AM/SSB/CW

Receiver


GR Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
GR-54 0.18-30 MHz AM/SSB
1966-1971 Receiver
GR-64 0.55-30 MHz AM/CW
1964-1971 Receiver
GR-78 0.14-18 MHz AM/CW
1969-1977 Receiver
GR-81 0.2-30 MHz AM/SSB/CW
1961-1972 Receiver
GR-88 152-174 MHz FM

Receiver
GR-91 0.55-30 MHz AM/CW
1961-1963 Receiver


GW Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type Channels
GW-12A 26.965-27.255 MHz AM

Transceiver 1
GW-22A 26.965-27.255 MHz AM

Transceiver 5
GW-32A 26.965-27.255 MHz AM

Transceiver 5


HR Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
HR-10 10-80 m AM/CW

Receiver
HR-20 10-80 m AM/CW

Receiver
HR-1680 10-80 m SSB/CW

Receiver


HW Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
HW-2M 144-148 MHz FM 5 W
Transceiver - VHF - Handheld
HW-2P 144-148 MHz FM 5 W
Transceiver - VHF - Handheld
HW-4M 438-450 MHz FM 5 W
Transceiver - UHF - Handheld
HW-4P 438-450 MHz FM 5 W
Transceiver - UHF - Handheld
HW-7 15-40 m CW 3 W
Transceiver - HF - Base
HW-8 15-80 m CW 2.5 W
Transceiver - HF - Base
HW-9 10-80 m CW 5 W WARC option Transceiver - HF - Base
HW-10 6 m AM/CW 10 W
Transceiver - VHF/UHF - Base
HW-12 80 m LSB 100 W
Transceiver - HF - Base
HW-12A 80 m SSB 100 W
Transceiver - HF - Base
HW-16 15/40/80 m CW 90 W 1967-1976 Transceiver - HF - Base
HW-17 2 m AM

Transceiver - VHF/UHF - Base
HW-18 ?? SSB

Transceiver - HF - Base
HW-19 10 m AM 5 W XTAL Transceiver - HF - Base
HW-20 2 m AM/CW 10 W
Transceiver - VHF - Base
HW-22 40 m SSB ?? W
Transceiver - HF - Base
HW-24 438-450 MHz FM 5 W
Transceiver - UHF - Base
HW-24H 438-450 MHz FM 5 W
Transceiver - UHF - Base
HW-24HT 438-450 MHz FM 5 W
Transceiver - UHF - Handheld
HW-29A 6 m AM 5 W XTAL Transceiver - VHF/UHF - Base
HW-30 2 m AM 5 W XTAL Transceiver - VHF/UHF - Base
HW-32 20 m SSB ?? W
Transceiver - HF - Base
HW-101 10-80 m SSB/CW 100 W
Transceiver - HF - Base
HW-104 ? ?

Transceiver - HF - Base
HW-202 2 m FM 10 W XTAL Transceiver - VHF/UHF - Base
HW-2036 2 m FM 10 W
Transceiver - VHF/UHF - Mobile
HW-5400 10-80 m ?

Transceiver - HF - Base


HWS Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
HWS-2 2 m FM 3 W
Transceiver - VHF - Handheld
HWS-2XL 2 m FM 5 W
Transceiver - VHF - Handheld
HWS-4 70 cm FM 3 W
Transceiver - UHF - Handheld
HWS-4XL 70 cm FM 5 W
Transceiver - UHF - Handheld


HX Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
HX-10 (Marauder) 10-80 m AM/SSB/CW/FSK 180 W
Transmitter
HX-11 10-80 m CW 50 W
Transmitter
HX-20 10-80 m SSB 50 W
Transmitter
HX-30 10-80 m SSB 10 W
Transmitter
HX-1675 10-80 m CW 35 W
Transmitter
HX-1681 10-80 m CW 100 W
Transmitter


MR Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
MR-1 (Comanche) 10-80 m AM/SSB/CW
1959-1962 Receiver
MR-18 (Mariner) 0.19-0.41 / 0.535-1.605 MHz AM
197x-197x Receiver
MR-1010 0.18-0.42 / 0.54-11.5 MHz AM/SSB/CW
197x-197x Receiver


MT Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
MT-1 (Cheyenne) 10-80 m Phone or CW

Transmitter


RA Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
RA-1 10-160 m AM/SSB/CW

Receiver


RG Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
RG-1 0.6-32 MHz AM/SSB/CW

Receiver


RX Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
RX-1 (Mohawk) 10-160 m AM/SSB/CW
1958-1964 Receiver


SB Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
SB-100 10-80 m SSB/CW 100 W 1965-1967 Transceiver - HF - Base
SB-101 ? ?

Transceiver - HF - Base
SB-102 ? ?

Transceiver - HF - Base
SB-104 10-80 m ?

Transceiver - HF - Base
SB-104A 10-80 m ?

Transceiver - HF - Base
SB-110 6 m SSB/CW 100 W
Transceiver - VHF/UHF - Base
SB-300 10-80 m AM/SSB/CW
196x-19xx Receiver
SB-301 10-80 m AM/SSB/CW
1966-1970 Receiver
SB-303 10-80 m AM/SSB/CW/RTTY

Receiver
SB-310 3.5-27.4 MHz AM/SSB/CW
1968-1972 Receiver
SB-313 ????? MHz AM/SSB/CW
1968-1972 Receiver
SB-401 10-80 m SSB/CW 100 W
Transmitter
SB-1400 10-160 m + WARC AM/FM/SSB/CW 100 W
Transceiver - HF - Base


SS Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
SS-9000 10-160 m + WARC SSB/CW 100 W
Transceiver - HF - Base


SW Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
SW-717 560 KHz-30 MHz AM/SSB/CW
1968-1972 Receiver
SW-7800 0.15-30 MHz AM/SSB/CW
1984-1990 Receiver


TX Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
TX-1 (Apache) ?-? m ? ? W
Transmitter


VF Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
VF-2031 2 m FM 2 W XTAL Transceiver - Handeld
VF-7401 2 m FM 15 W
Transceiver - Mobile/Base


VHF Series

Pics Model Band/Frequency Range Modes Max P/O Comments Type
VHF-1 (Seneca) 2m & 6m Phone/CW 140 W XTAL Transmitter - Base
